| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXP-8090S-D17L90 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range（MHz）: | 806～960 | Polarization: | ±45º |
|---|---|---|---|
| Gain（dBi）: | 2×16.5 | Half-power Beam Width（°）: | H:90 V:7 |
| VSWR: | ≤1.5 | Lightning Protection: | DC Ground |
| Input Connector Type: | 2-N Female | Mounting Hardware（mm）: | ￠35～￠90 |
| Highlight: | wifi panel,outdoor antenna wifi,wifi antennas |
||
806-960MHz Directional Panel Antenna
AMXP-8090S-D17L90
Feature:
High gain
Full day working
Optimized dimension
Dual polarization
Application:
CDMA,GSM system
Wireless communication and data transmission system
|
AMXP-8090S-D17L90 Electrical Specifications |
|
|
Frequency range(MHz) |
806～960 |
|
Polarization |
±45º |
|
Gain(dBi) |
2×16.5 |
|
Half-power beam width(°) |
H:90 V:7 |
|
Front-to-back ratio(dB) |
≥23 |
|
Input Impedance(Ω) |
50 |
|
VSWR |
≤1.5 |
|
Isolation between ports |
≥28dB |
|
Cross-polar ratio |
≥15dB@0º ≥10dB@+/-60º |
|
Sidelobe suppression for first sidelobe above horizon |
15 dB |
|
Maximum input power(W) |
400 |
|
Lightning protection |
DC Ground |
|
Mechanical Specifications |
|
|
Input connector type |
2-N Female |
|
Dimensions-mm (Height/Width/Depth) |
2430*280*125 |
|
Packing size(mm) |
2480*320*210 |
|
Antenna weight (kg) |
15 |
|
Radome material |
UPVC |
|
Radome color |
Gray |
|
Mechanical tilt(°) |
0～10 |
|
Operating temperature(°c) |
-40～60 |
|
Rated Wind Velocity(m/s) |
60 |
|
Mounting hardware(mm) |
￠35～￠90 |
