| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXW-2400-10A |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range（MHz）: | 2400-2483 | Bandwidth（MHz）: | 83 |
|---|---|---|---|
| Gain（dBi）: | 10 | VSWR: | ≤1.5 |
| Polarization: | Vertical | Lightning Protection: | DC Ground |
| Input Connector Type: | RP-SMA Male Or Requested | Mounting Way: | Wall-hanging Or Pole-holding |
| Highlight: | wifi antenna,wifi outdoor antenna,wifi patch antenna |
||
Ameison 2.4GHz Panel Antenna
Factory price
Superior performance
Mounting kits included
Waterproof heavy-duty ABS redome
2400-2483MHz Directional Wall Mount Antenna
AMXW-2400-10A
Feature:
High gain,strong anti-interference ability
Good defense system
Full day working
Exquisite appearance
Optimized dimension
Application:
2.4GHZ WLAN system
2.4GHZ ISM frequency band
WIFI system
|
AMXW-2400-10A Electrical Specifications |
|
|
Frequency range(MHz) |
2400-2483 |
|
Bandwidth(MHz) |
83 |
|
Gain(dBi) |
10 |
|
Half-power beam width(°) |
H:50 V:50 |
|
VSWR |
≤1.5 |
|
Input Impedance(Ω) |
50 |
|
Polarization |
Vertical |
|
Maximum input power(W) |
50 |
|
Lightning protection |
DC Ground |
|
Input connector type |
RP-SMA Male or Requested |
|
Mechanical Specifications |
|
|
Dimensions-mm (Height/Width/Depth) |
140*120*25 |
|
Antenna weight(kg) |
0.3 |
|
Operating temperature(°c) |
-40～60 |
|
Rated Wind Velocity(m/s) |
60 |
|
Radome material |
ABS |
|
Radome color |
white |
|
Mounting way |
wall-hanging or pole-holding |
|
Mounting hardware(mm) |
￠35～￠50 |
