| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXP-3500S-D14L90 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range（MHz）: | 3400～3600 | Polarization: | ±45º |
|---|---|---|---|
| Gain（dBi）: | 2×14 | Half-power Beam Width（°）: | H:90 V:14 |
| VSWR: | ≤1.5 | Lightning Protection: | DC Ground |
| Input Connector Type: | 2-N Female | Mounting Hardware（mm）: | ￠35～￠75 |
| Highlight: | wimax antenna,wimax antenna outdoor,3.5g wimax antenna |
||
Wimax Base Station Antenna
Factory price
All weather operation
Included mounting bracket
Heavy-duty UV-resistant Racome
3400-3600MHz Directional Panel Antenna
AMXP-3500S-D14L90
Feature:
High gain
Full day working
Optimized dimension
Dual polarization
Application:
3.3 GHz to 3.8 GHz (3350-3800 MHz) Band Applications
Integrated Radio/Antenna Applications
WiMAX , Mobile WiMAX & SOFDMA
IEEE 802.16e Applications
Amplified Antenna Applications
AMXP-3500S-D14L90 Electrical Specifications | |
Frequency range(MHz) | 3400～3600 |
Polarization | ±45º |
Gain(dBi) | 2×14 |
half-power beam width(°) | H:90 V:14 |
Front-to-back ratio(dB) | ≥23 |
Input Impedance(Ω) | 50 |
VSWR | ≤1.5 |
Isolation between ports | ≥28dB |
Cross-polar ratio | ≥15dB@0º ≥10dB@+/-60º |
Sidelobe suppression for first sidelobe above horizon | 15 dB |
Maximum input power(W) | 200 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | 2-N Female |
Dimensions-mm (Height/Width/Depth) | 410*114*54 |
Packing size(mm) | 450*130*110 |
Antenna weight (kg) | 2.5 |
Radome material | UPVC |
Radome color | Gray |
Mechanical tilt(°) | 0～10 |
Operating temperature(°c) | -40～60 |
Rated Wind Velocity(m/s) | 60 |
Mounting hardware(mm) | ￠35～￠75 |
