| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXW-5800VH-D15L60 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range(MHz): | 5725 - 5850 | Polarization: | Vertical And Horizontal |
|---|---|---|---|
| Gain（dBi）: | 2×15 | Half-power Beam Width（°）: | H: 60 V: 14 |
| Lightning Protection: | DC Ground | Input Connector Type: | 2-N Female |
| Highlight: | wireless antenna,wireless antenna 50km,wifi wireless antenna 30km |
||
5.8 GHz WiFi Wireless Antenna
Factory price
All weather operation
Included Mounting bracket
Heavy-duty UV-Resistant Radome
5.8 GHz Dual Polarized 15 dBi Flat Panel WiFi Wireless Antenna
Model No.: AMXP-5800VH-D15L60
Superior Performance
The AMXP-5800VH-D15L60 Flat Panel Antenna combines vertical and horizontal polarization with high gain
over multiple frequencies in a single enclosure. It is a professional quality antenna designed primarily for MIMO
point-to-multipoint and point-to-point applications in the 5.8 GHz frequency bands.
This antenna incorporates advanced dual polarization technology that allows for the interoperability of two radios
to transmit and receive paths.
This technology allows for the attenuation of unwanted signals from adjacent channelsand/or co-located equipment.
Rugged and Weatherproof
This aesthetically pleasing antenna features a heavy-duty UV-resistant plastic radome ideal for all-weather indoor
and outdoor operation. The AMXP-5800VH-D15L60 antenna is supplied with a tilt and swivel mast mount kit.
This allows quick installation at various degrees of up/down tilt for easy alignment.
AMXW-5800VH-D15L60 Electrical Specifications | |
Frequency range(MHz) | 5725～5850 |
Polarization | Vertical and Horizontal |
Gain(dBi) | 2×15 |
Half-power beam width(°) | H: 60 V: 14 |
Front-to-back ratio(dB) | ≥25 |
Input Impedance(Ω) | 50 |
VSWR | ≤1.5 |
Isolation between ports(dB) | ≥28 |
Cross-polar ratio(dB) | ≥15@0º ≥10@+/-60º |
Sidelobe suppression for first sidelobe above horizon(dB) | 15 |
Maximum input power(W) | 200 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | 2-N Female |
Dimensions-mm (Height/Width/Depth) | 220*122*25 |
Packing size(mm) | 260*160*90 |
Antenna weight (kg) | 0.37 |
Radome material | ABS |
Radome color | White |
Mechanical tilt(°) | 0～10 |
Operating temperature(°c) | -40～60 |
Rated Wind Velocity(m/s) | 60 |
Mounting hardware(mm) | ￠30～￠50 |
