| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXW-5158VH-D15L60 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range（MHz）: | 5100～5850 | Polarization: | Vertical And Horizontal |
|---|---|---|---|
| Gain（dBi）: | 2×15 | Half-power Beam Width（°）: | H: 60 V: 14 |
| VSWR: | ≤1.5 | Lightning Protection: | DC Ground |
| Input Connector Type: | 2-N Female | ||
| Highlight: | Mimo Antenna,outdoor wifi antenna,wireless antenna outdoor |
||
Factory Price
5100-5850MHz Mimo Antenna
AMXW-5158VH-D15L60
Feature:
High gain
Full day working
Optimized dimension
Vertical or horizontal Polarization
Application:
5.1 GHz～5.8 GHz WLAN system
5.1 GHz～5.8 GHz ISM frequency band
|
AMXW-5158VH-D15L60 Electrical Specifications |
|
|
Frequency range(MHz) |
5100～5850 |
|
Polarization |
Vertical and Horizontal |
|
Gain(dBi) |
2×15 |
|
Half-power beam width(°) |
H: 60 V: 14 |
|
Front-to-back ratio(dB) |
≥25 |
|
Input Impedance(Ω) |
50 |
|
VSWR |
≤1.5 |
|
Isolation between ports(dB) |
≥28 |
|
Cross-polar ratio(dB) |
≥15@0º ≥10@+/-60º |
|
Sidelobe suppression for first sidelobe above horizon(dB) |
15 |
|
Maximum input power(W) |
200 |
|
Lightning protection |
DC Ground |
|
Mechanical Specifications |
|
|
Input connector type |
2-N Female |
|
Dimensions-mm (Height/Width/Depth) |
220*122*25 |
|
Packing size(mm) |
260*160*90 |
|
Antenna weight (kg) |
0.37 |
|
Radome material |
ABS |
|
Radome color |
White |
|
Mechanical tilt(°) |
0～10 |
|
Operating temperature(°c) |
-40～60 |
|
Rated Wind Velocity(m/s) |
60 |
|
Mounting hardware(mm) |
￠30～￠50 |
